41
PROGRAMMING FEATURES
To program, connect the XT Series radio via
the Drop-in Charger Tray and CPS
Programming Cable as shown in Figure 1 on
page 40. Toggle the cable switch of the CPS
Programming Cable to ‘CPS Mode’.
CPS allows you to program frequencies, PL/
DPL Codes as well as other features such as:
Time-out Timer, Scan List, Call Tones,
Scramble, Reverse Burst, etc. CPS is a very
useful tool as it can also lock the Front-Panel
Radio Programming or restrict any specific
radio feature to be changed (to avoid
accidentally erasing the preset radio values). It
also provides security by giving the option to
set up a password for profile radio’s
management. For more information, refer to
Features Summary Chart Section at the end of
the User Guide.
Note: (*) CPS Programming Cable P/N#
HKKN4027_ is an accessory sold
separately. Please contact your Motorola
Solutions point of purchase for more
information.
Time-Out Timer
Transmissions can be terminated when the
PTT button is pressed by setting up a Time-Out
Timer.
Reverse Burst
Reverse Burst eliminates unwanted noise
(squelch tail) during loss of carrier detection.
You can select values of either 180 or 240 to be
compatible with other radios.
• The features described in previous pages are just
some of the features CPS has. CPS offers more
capabilities. For more information refer to the
HELP file in the CPS.
• Some of the features available with the CPS
software may vary depending on the radio model.
63M03_A_BRCAN_en.book Page 41 Monday, November 19, 2018 10:16 AM
