Motostar ECLISTAR - Electrical Connections

L
N
Pag.
23
23 -
Manual code:
119R7179GB
119 R7179 G B ver.
3.0
3.0 07/2009
- The data and information in this manual are subject to change at any time.
3.3 ELECTRICAL CONNECTIONS
Power supply
230V (A.C.)
50/60z
M
OTOR A, DELAYED CLOSING:
THE GATE LEAF OPENS FIRST AND
CLOSES SECOND *
M
OTOR B,
DELAYED OPENING:
THE GATE LEAF OPENS
SECOND AND CLOSES
FIRST *
Transformer
Phase
Neutral
Brown
Black
Blue
Brown
Black
Blue
White
Black
Orange
Grey
Purple
Brown
Blue
Red
* to prevent any mechanical interference
between the gate leaves
GEARMOTORS, TRANSFORMER AND POWER SUPPLY
