Motostar ECLISTAR - Limits to Use

240
max
AC
330
330
B
(mm)
Pag.
6
- Manual code:
119R7179GB
119 R7179 G B ver.
3.0
3.0 07/2009 - The data and information in this manual are subject to change at any time.
1.5 LIMITS TO USE
Opening angle A B C
90°
140÷205 0÷50 430
140÷195 75÷100 430
140÷185 125÷150 400
140÷175 175÷200 400
110°
180÷210 0 430
200÷205 50 430
The maximum width of the gate leaf must not exceed 2.2 metres and its max weight
cannot exceed 300 kg.
