1.4 MAIN COMPONENT PARTS OF A STANDARD INSTALLATION
1) Flashing light with built-in antenna
2) Keypad selector
3) Control panel
4) Photocell
5) Junction box for passage of electrical cables
6) Gearmotors
7) Transmitters
The standard installation shown is only an example.
Check the illustrations and the contents list in the kit box you
have purchased.
Number of wires per cable section
