Mounting Systems Premium Series - Elements and Components








Installation manual
2.1 Elements and components
Base rail
° mm (-)
° mm (-)



Locking front support 250mm (600-0365)
Connecting profil south 585mm (600-0371)
Connecting rail 1025mm (600-0370)
Connecting rail 1475mm (600-0374)
Connecting rail 1293mm (600-0375)
Front support (814-0703) Rear support (711-0260)
Ballast tray
1831mm, max. 120kg (801-0373)
2037mm, max. 120kg (801-0374)
2171mm, max. 120kg (801-0375)
2327mm, max. 100kg (801-0384)
Adapter wind deflector
40mm (600-0361)
Ball locking pin
x (807-0351)
