Mounting Systems Premium Series - Assembly: Front Support; Install Front Support in Base Rail; Lock Rail with Component

9
FD3-S Premium Line Montage
3.2 Front support

. Install the front support (5) in the cutouts
at the side edge of the base rail (1)
. Lock together with the rail (2). Assembling the protection mat
CLICK
At the beginning of the system
lock with component (2)












up to an audible clickPprotection mat beneath the
front and middle support
