Direction
Allows an operator to set the direction for capturing the torque readings: (Clockwise, Counter Clockwise and Both
directions).
When performing a dead weight calibration, the direction should be set for both directions.
Direction
Direction Setting
Direction: BOTH
Main
1. Press the "Menu" Button .
2. Use the Scroll Down key and select Setup by highlighting and pressing Enter.
3. Use the Scroll Up or Down key to toggle through the Setup options.
4. Press Enter key to select a setup setting for Direction.
Filter
Units
Mode
Setup
Selecting Direction
1. Use the Scroll Up or Down key to toggle through the dIrection settings:
(Both, CW, CCW)
2. Press Enter key once setting is complete.
3. Press Main button to return to main display screen.
Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733
www.etorque.com
Page 16
