Screen Display
When the Torque Analyzer is turned on and it is connected to a Mountz "Smart" Torque Transducer with ARCII technolo-
gy it will display a Screen similar to that below for 5 seconds and then go into Reading Mode. This will also happen if a
"Smart" transducer is disconnected and another smart transducer is connected. It will automatically detect if the sensor is
a torque or force sensor.
Mountz PTT-2000
Version 1.06k
Tool Model
BMX250i
Serial Number
04-93-071
If an un-calibrated torque transducer or force sensor is connected then the Analyzer will display a screen as below.
Note:
The PTT supports Non-Smart torque transducers & force sensors as well as Non-Mountz transducers. Non-
smart transducers can be detected and can be calibrated in the "internal" memory. The PTT will offer 2
choices. It offers to calibrate or choose from a list of transducers stored in the internal memory.
Mountz PTT-2000
Version 1.06k
Uncalibrated Transducer -
Connect to Calibration
Software
Note:
When disconnecting a smart transducer and connecting another, the operator must unplug the cable from the
PTT unit.
