lbf.in
lbf.ft
ozf.in
kgf.cm
kgf.m
N.m
Menu Selections
1. Select Units by highlighting and pressing Enter.
2. Use the Scroll Up or Down key to toggle through the Unit options.
3. Press Enter key to select a Filter Setting.
Filter
Units
Mode
Setup
Selecting Units
Note:
When a torque sensor is connected,
the PTT lists only torque units. Also,
cN.m is also available but you must
scroll down.
When a force sensor is connected,
the PTT lists only force units.
Track
Peak
First Peak
Audit
Torque + Angle
Bolt Audit
1. Select Mode by highlighting and pressing Enter.
2. Use the Scroll Up or Down key to toggle through the Mode options.
3. Press Enter key to select a Mode Setting.
4. The Main (or reading screen) will display the value of the selected Mode.
Filter
Units
Mode
Setup
Selecting Mode Options
Tolerance
Auto Clear
Angle Setup
T+A Threshold
First Peak
Bolt Audit
1. Select Setup by highlighting and pressing Enter.
2. Use the Scroll Up or Down key to toggle through the Setup options.
3. Press Enter key to select a Setup Setting.
Filter
Units
Mode
Setup
Selecting Setup
Note:
Spindle Audit, Direction, Clock,
Contrast, Language, & Sleep is also
available but you must scroll down.
The Bolt Audit Mode is an additional
feature that is only available with
PTT Bolt Audit model (Item #
072995)
Main Cancel
Main Cancel
Main
Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733
www.etorque.com
Page 7
For Torque Sensors
lbf
kN
Track
Peak
Note:
When a torque sensor is connected,
the PTT lists only modes it can
operate with.
When a force sensor is connected,
the PTT lists only modes it can
operate with.
The Bolt Audit Mode is an additional
feature that is only available with
PTT Bolt Audit model (Item #
072995)
For Force Sensors
For Torque Sensors For Force Sensors
To Next Page
