EDS-408A/405A Series User’s Manual Featured Functions

3-24

Explanation of “Settings” Items

Redundancy Protocol

Setting Description Factory Default

Turbo Ring

Select this item to change to the

Turbo Ring configuration page.

Turbo Ring V2

Select this item to change to the

Turbo Ring V2 configuration page.

RSTP (IEEE

802.1W/1D)

Select this item to change to the

RSTP configuration page.

None Ring redundancy is not active

None

Set as Master

Setting Description Factory Default

Enabled Select this EDS as Master

Disabled Do not select this EDS as Master

Not checked

Redundant Ports

Setting Description Factory Default

1st Port

Select any port of the EDS to be

one of the redundant ports.

EDS-405A

: port 4

EDS-408A

: port 7

2nd Port

Select any port of the EDS to be

one of the redundant ports.

EDS-405A

: port 5

EDS-408A

: port 8

Enable Ring Coupling

Setting Description Factory Default

Enable Select this EDS as Coupler

Disable Do not select this EDS as Coupler

Not checked

Coupling Port

Setting Description Factory Default

Coupling Port

Select any port of the EDS to be the

coupling port

EDS-405A

: port 2

EDS-408A

: port 5

Coupling Control Port

Setting Description Factory Default

Coupling Control Port

Select any port of the EDS to be the

coupling control port

EDS-405A

: port 3

EDS-408A

: port 6
