EDS-408A/405A Series User’s Manual Featured Functions
3-54
Using the MAC Address Table
This section explains the information provided by the EDS’s MAC address table.
The MAC Address table can be configured to display the following EDS MAC address groups.
ALL Select this item to show all EDS MAC addresses
ALL Learned Select this item to show all EDS Learned MAC addresses
ALL Static Lock Select this item to show all EDS Static Lock MAC addresses
ALL Static Select this item to show all EDS Static/Static Lock /Static Multicast
MAC addresses
ALL Static Multicast Select this item to show all EDS Static Multicast MAC addresses
Port x Select this item to show all MAC addresses of dedicated ports
The table will display the following information:
MAC This field shows the MAC address
Type This field shows the type of this MAC address
Port This field shows the port that this MAC address belongs to
Priority This field shows the priority of this MAC address
