EDS-408A/405A Series User’s Manual Featured Functions
3-11
NOTE
The Turbo Ring Ports and Coupling Ports will be added to all VLANs if you enable the “Turbo
Ring DIP Switch” and set Turbo Ring DIP Switch from OFF to ON.
NOTE
If you enable the Hardware DIP Switch for Turbo Ring and set the Turbo Ring DIP Switch from
ON to OFF, then the Ring Ports and Coupling Ports which are added to all VLANs are restored
to their previous software settings. (For details on how to do this, please refer to “Using Virtual
LAN”).
System File Update—By Remote TFTP
MOXA EtherDevice Switch supports saving your configuration file to a remote TFTP server or
local host to allow other EtherDevice Switches to use the same configuration at a later time, or
saving the Log file for future reference. Loading pre-saved firmware or a configuration file from
the TFTP server or local host is also supported for easy upgrading or configuration of the
EtherDevice Switch.
TFTP Server IP/Name
Setting Description Factory Default
IP Address of the
TFTP Server
The IP or name of the remote TFTP server.
Must be set up before downloading or
uploading files.
None
Configuration file path and name
Setting Description Factory Default
Max. 40
Characters
The path and file name of the EtherDevice
Switch’s configuration file on the TFTP
server.
None
Firmware file path and name
Setting Description Factory Default
Max. 40
Characters
The path and file name of the EtherDevice
Switch’s firmware file.
None
