Moxa Technologies EtherDevice EDS-405A-PTP Series User Manual

- 12 -
STATE, CPLR/TAIL and MSTR/HEAD
Relay Contact
One relay output with current carrying capacity of 1A
@ 24 VDC
DIP Switches
Master, Coupler, Turbo Ring, Reserve
Power
Input Voltage
12/24/48 VDC (9.6 to 60 VDC), redundant
dual inputs
Input Current (@ 24 V)
Max. 0.24 A
Connection
One removable 6-pin terminal block
Overload Current Protection
Present
Reverse Polarity Protection
Present
Physical Characteristics
Housing
Metal, IP30 protected
Dimensions
53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in)
Weight
650 g
Installation
DIN-Rail, Wall Mounting (optional kit)
Environmental Limits
Operating Temperature
-10 to 60C (14 to 140F);
-40 to 75°C (-40 to 167°F ) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5% to 95% (non-condensing)
Regulatory Approvals
EMI
FCC Part 15 Subpart B Class A,
EN 61000-6-4
EMS EN 61000-4-2 (ESD), Level 3
EN 61000-4-3 (RS), Level 3
EN 61000-4-4 (EFT), Level 3
EN 61000-4-5 (Surge), Level 3
EN 61000-4-6 (CS), Level 3
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
WARRANTY
5 years
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
+86-21-5258-9955
Fax:
+86-21-5258-5505
Moxa Europe
:
Tel:
+49-89-3 70 03 99-0
Fax:
+49-89-3 70 03 99-99
Moxa Asia
-Pacific:
Tel:
+886-2-8919-1230
Fax:
+886-2-8919-1231
