Moxa Technologies EtherDevice EDS-405A-PTP Series User Manual

- 11 -
CPLR/TAIL GREEN
On
1. The switch’s coupling function is
enabled to form a back-up path
2. When it’s set as the Tail of the
Turbo Chain.
3. POST S.W. Fails (+Stat on and
Fault blinking)
Blinking
1. Turbo Chain is down.
2. The switch is set as Turbo Chain’s
Member and the corresponding
chain port is down.
Off
1. This switch has disabled the
coupling function.
2. This switch is set as a Member of
the Turbo Chain.
STATE+FAULT
+MSTR/HEAD+
CPLR/TAIL
Blinking
The switch is being
discovered/located by
MXview(2time/s)
10M
(TP)
GREEN
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10
Mbps.
Off
TP Port’s 10 Mbps link is inactive.
100M
(TP)
GREEN
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100
Mbps.
Off
TP Port’s 100 Mbps link is inactive.
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the
EDS-405A-PTP’s 10/100BaseTX ports to any kind of Ethernet device,
without needing to pay attention to the type of Ethernet cable being used
for the connection. This means that you can use either a straight-through
cable or cross-over cable to connect the EDS-405A-PTP to Ethernet
devices.
Specifications
Technology
Standards
IEEE802.3, 802.3u, 802.3x, 802.1D, 802.1Q,
802.1w, 802.1p, 802.1X, 802.1s
Protocols IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP
Server/Client, DHCP Option 66/67/82, BootP
, TFTP,
SNTP, SMTP, RARP, RMON, HTTP, HTTPS, Telnet,
SSH, Syslog, EtherNet/IP, Modbus/TCP, PROFINET,
SNMP Inform, LLDP, IEEE 1588 PTP V2, IPv6, NTP
Server/Client
MIB MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, RMON
MIB Group 1, 2, 3, 9, Bridge MIB, RSTP MIB
Processing Type
Store and Forward
Flow Control
IEEE802.3x flow control, back pressure flow control
Interface
RJ45 Ports
10/100BaseT(X) auto negotiation speed, F/H duplex
mode, and auto MDI/MDI-X connection
Console
RS-232 (RJ45)
LED Indicators
PWR1, PWR2, FAULT, 10/100M (TP port),
