Standards IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X) and 100BaseFX,
IEEE 802.3ab for 1000Base-T
IEEE 802.3z for 1000Base-X
IEEE 802.3x for Flow Control
IEEE 802.3af for PoE
RJ45 Ports 10/100/1000Base-T(X) auto negotiation speed,
F/H duplex mode, and auto MDI/MDI-X connection
Fiber Ports 1000 Base-X ports (SFP Slot)
LED Indicators Power: P1, P2
TP Port: 10/100/1000
Fiber Port: 1000
PoE Ports: PoE+ for Port 2,3,4,5
enable/disable broadcast storm protection
Input Current 6.83 / 3.28 A (with full PoE+ loading)
Removable 4-contact terminal block
Always use an “isolated power supply” to
conform to the UL 508 standard.
Note: We strongly recommend using an isolated power supply with
maximum output current of 7.5 A due to the power de-rating issue of the
power supply at high operating temperatures. Moreover, without
galvanic isolation between the redundant power inputs of this device, the
V1+ and V2+ should use the same voltage.
Physical Characteristics
Housing Aluminum, IP30 protection
Dimensions 29 (W) x 135 (H) x 105 (L)
Weight 300 g
Installation DIN-Rail Mounting, Wall Mounting (with optional
Standard models: 0 to 60°C (32 to 140°F)
Wide temp. models: -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative
5 to 95% (non-condensing)
FCC Part 15, CISPR (EN55022) class A
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
