MGate MB3000 Modbus Gateway User Manual
49
Network Settings
The Network tab is where the unit’s network settings are configured. You can modify the Name, Network
Configuration, IP Address, Netmask, Default Gateway, and DNS.
Ethernet Settings
Parameter
Value
Notes
IP Configuration Static IP, DHCP, BOOTP
Select Static IP if you are using a fixed IP address. Select
one of the other options if the IP address is set dynamically.
IP Address
192.168.127.254
(or other 32-bit number)
The IP (Internet Protocol) address identifies the server on
the TCP/IP network.
Netmask
255.255.255.0
(or other 32-bit number)
This identifies the server as belonging to a Class A, B, or C
network.
Gateway
0.0.0.0
(or other 32-bit number)
This is the IP address of the router that provides network
access outside the server’s LAN.
DNS Server
Parameter
Value
Notes
DNS Server 1
0.0.0.0
(or other 32-bit number)
This is the IP address of the primary domain name server.
DNS Server 2
0.0.0.0
(or other 32-bit number)
This is the IP address of the secondary domain name server.

Moxa Technologies MGate MB3180 Specifications

General

Full duplex	Yes
Data transfer rate	0.1 Gbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Interface	RS-232/422/485, RJ45
Safety	UL 60950-1, EN 60950-1
Certification	EN 55024, \\r EN 61000-4-2 (ESD) Level 2, \\r EN 61000-4-3 (RS) Level 2, \\r EN 61000-4-4 (EFT) Level 2, \\r EN 61000-4-5 (Surge) Level 2, \\r EN 61000-4-6 (CS) Level 2, \\r EN 61000-4-8, \\r EN 61000-4-11, \\r EN 61000-4-12
LED indicators	Power
Compatible operating systems	Windows 98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64

Weight and Dimensions

Weight	340 g
