MGate MB3000 Modbus Gateway User Manual
62
E-mail Alert
Along with activating “Mail” function from events on Auto Warning Settings page, the E-mail alert should
be setup then. Please note that this feature is not supported on MB3180 gateway.
Parameters
Description
Mail server
The mail server’s domain name or IP address.
Username
This field is for your mail server’s user name, if required.
Password
This field is for your mail server’s password, if required.
From e-mail address
This is the e-mail address from which automatic e-mail warnings will be sent.
To e-mail address 1 to 4
This is the e-mail address or addresses
SNMP Trap
Along with activating the Trap function from events on the Auto Warning Settings page, the SNMP Trap
should be set up. Please note that this feature is not supported on the MB3180 gateway.
Parameters
Description
SNMP trap server IP
Use this field to indicate the IP address to use for receiving SNMP traps.
Trap version
Use this field to select the SNMP trap version.
Trap community
Use this field to designate the SNMP trap community.

Moxa Technologies MGate MB3180 Specifications

General

Full duplex	Yes
Data transfer rate	0.1 Gbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Interface	RS-232/422/485, RJ45
Safety	UL 60950-1, EN 60950-1
Certification	EN 55024, \\r EN 61000-4-2 (ESD) Level 2, \\r EN 61000-4-3 (RS) Level 2, \\r EN 61000-4-4 (EFT) Level 2, \\r EN 61000-4-5 (Surge) Level 2, \\r EN 61000-4-6 (CS) Level 2, \\r EN 61000-4-8, \\r EN 61000-4-11, \\r EN 61000-4-12
LED indicators	Power
Compatible operating systems	Windows 98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64

Weight and Dimensions

Weight	340 g
