MGate MB3000 Modbus Gateway User Manual
78
Import Function
Once the file is saved, it can be imported into your target unit to duplicate the same settings. Select the
target unit first and click the Import button to import.
Select the file you want to import, and then click the OK button
Wait for the MGate Manager to finish configuring the target device. If you import the configuration file
successfully, a confirmation message will pop up. After closing the message dialog, the MGate Manager will
automatically execute a Broadcast Search for all MGate units on the LAN. Your MGate should reappear in the
list of units.
ATTENTION
DO NOT turn off the MGate power before the firmware upgrade process is completed. The MGate will be
erasing the old firmware to make room for the new firmware to flash memory. If you power off the MGate
and terminate the process, all settings will disappear, and the MGate gateway will revert to factory
defaults. If this happens, import the settings from the file again.

Moxa Technologies MGate MB3180 Specifications

General

Full duplex	Yes
Data transfer rate	0.1 Gbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Interface	RS-232/422/485, RJ45
Safety	UL 60950-1, EN 60950-1
Certification	EN 55024, \\r EN 61000-4-2 (ESD) Level 2, \\r EN 61000-4-3 (RS) Level 2, \\r EN 61000-4-4 (EFT) Level 2, \\r EN 61000-4-5 (Surge) Level 2, \\r EN 61000-4-6 (CS) Level 2, \\r EN 61000-4-8, \\r EN 61000-4-11, \\r EN 61000-4-12
LED indicators	Power
Compatible operating systems	Windows 98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64

Weight and Dimensions

Weight	340 g
