Optional Accessories (can be purchased separately)
Cables
• CBL-USBA/B-100: USB Type A to USB Type B cable, 100 cm
• CBL-F9M9-150: DB9 female to DB9 male serial cable, 150 cm
• CBL-F9M9-20: DB9 female to DB9 males serial cable, 20 cm
• CBL-RJ45SF9-150: RJ45 to DB9 female shielded serial cable, 150 cm
• ADP-RJ458P-DB9: DB9 female to RJ45 connector
Connectors
• Mini DB9F-to-TB: DB9 female to terminal block connector
• ADP-RJ458P-DB9F-ABC01: DB9 female to RJ45 connector
Mounting Kits
• DK35A: 35-mm DIN-rail mounting clips; 2 DIN-rail plates with 4 screws
For the UPort 1200
DK-UP1200: DIN-rail/wall- mounting kit that includes 2 wall-mounting plates with 6 screws (WK-35-02),
and 2 DIN-rail plates with 4 screws (DK35A)
For the UPort 1400/1600-8
DK-UP1400: DIN-rail/wall- mounting kit that includes 2 wall-mounting plates with 6 screws (WK-35-01),
and 2 DIN-rail plates with 4 screws (DK35A)
For the UPort 1600-16
WK-44-01: 19" rackmount L brackets; 2 L-shaped plates with 8 screws
Model name
DK-UP1200
DK-UP1200
WK-44-01
NOTE: Please notify your sales representative if any of the above items is missing or damaged.
Product Features
UPort 1200/1400/1600 Series products have the following features:
• Hi-Speed USB 2.0 supported (up to 480 Mbps)
• Additional I/O or IRQ not required
• Serial transmission speed up to 921.6 Kbps
• 128-byte FIFO and on-chip H/W, S/W flow control
