4.6 Operaonal indicators MFA
Display: LED 1 (yellow), „Ready“
Note: Generator is waing for switching-on command.
1
Generator running in the working range
Fig. 12 | MFA indicates ready for
operaon
Display: LED 1 (yellow), „Ready“
LED 2 (green), „Power on“
Note: Magnet liing material.
1
Aer switching-on command given via operang switch, the magnet lis
Fig. 13 | MFA indicates an acvated
magnet
2
Display LED 1 (yellow), „Ready“
LED 3 (red), „Power o“
Note: Magnet releases the material.
1
Aer switching-o command given via operang switch, magnet releases
load
Fig. 14 | MFA indicates the release of the
material
3
