MOZELT T4002 - Default Chapter; Table of Contents

To Next Page

To Previous Page

Table of Contents

1. Technical descripon 4

1.1 Range of applicaons 4

1.2 Descripon 4

1.3 Funcon mode 4

2. Technical data 5

2.1 Performance data 5

2.2 Accessories 5

2.2.1 Mul-funcon display MFA 5

2.2.2 Electrical cable connecons 5

2.2.3 Generator drives 5

3. Assembly, drawings 6

3.1 Assembling instrucons 6

3.2 Connecons 6

3.3 Dimensional drawings of generator 7

4. Start-up 8

4.1 Safety informaon 8

4.2 Safety regulaons magnet operaon 8

4.3 Operang instrucons 9

4.4 Overview mul-funcon display MFA 10

4.5 Structural design of current supply 10

4.6 Operaonal indicators MFA 11

4.7 Fault indicators MFA 12

All passages in the manual which are marked with the symbol „Warning“ contain

informaon which is important to avoid danger!

WARNING

All passages in the manual which are marked with the symbol „Cauon“ contain

informaon which is necessary to avoid damage to the current supply or to accessory

equipment!

CAUTION

www.mozelt.com

Englisch

MOZELT GmbH & Co. KG

Load liing magnet devices

Technical Manual: Electrical Power Supply T4002
