MOZELT T4002 - Technical Data

2. Technical data
2.1 Performance data
Model T 4002 13 kW 20 kW 30 kW
Rated voltage 230 V 230 V 230 V
Max. output current 56,5 A DC 87 A DC 130,5 A DC
Operang speed range * 2600....3400 rpm
Venlaon Internal venlator
Weight 58 kg 87 kg 135 kg
Protecon class IP 55
Permied ambient
temperature
-25° C…..+50° C non-condensing
Installaon height < 1000 m NN, above 1000 m output reducon of 1% per 100 m
2.2 Accessories
2.2.1 Multi-function display MFA
The dierent operang condions of the generator
are indicated in the funcon display (MFA) via LEDs.
An addional 6 LEDs indicate the working loading
ulizaon of the magnet (On/O rao) within the range
50…100%.
The release switch to turn the magnet on/o is also
aached to this display unit.
2.2.2 Electrical cable connections
The electrical cable connecons as well as the plug
connecons (plugs / coupler) are matched for the
respecve loads of the generators. The highest demands
are placed on funconality and safety.
If necessary, please use only original spare parts.
2.2.3 Generator drives
Depending on the version of the mobile excavator, the
generator is powered mechanically or hydraulically.
Both variants are designed in such a way that the
required rotaonal speed of the generator is ensured,
as soon as the diesel engine reaches its full speed.
With some hydraulic drives, opmal working is also
possible at low diesel speeds. In this respect, please check
the manual of the mobile excavator manufacturer.
Fig. 1 | Mul-funcon display MFA
Fig. 2 | Hydraulically powered 13 kW power supply
