4.7 Fault indicators MFA
LED 1 (yellow), „Ready“
- Interrupon in switch cable
- Operang switch defecve
- Control cable defecve
Aer switching-on command given via operang switch, no funcon
1
Fig. 15 | Switching-on command does
not react
LED 4 (red), „Line interrupt“
Aer switching-on command given via operang switch, „Line interrupt“
appears
4
Fig. 16 |MFA indicates „Line interrupt“
Aer switching-o command given via operang switch, LEDs ash
1
Fig. 17 | MFA indicates short-circuit
Display:
Possible cause:
Display:
Possible cause:
- Cable break in the 220 V circuit
- Magnet aached wrongly or not aached
- Cable or connector defecve
- Magnet defecve
Display:
Posible cause:
LED 1 -5 (ashing),
- Short-circuit in the cable system 220 V
- Full earth fault of the magnet
- Magnet too much power for electrical supply
2
3
4
5
