MPE SC2000 - Page 30

40010 √ √
40011 √ Wet Well Level (As shown on display with no decimal point)
40012 √ √ Setup Parameter - 1st Pump On Level
40013 √ √ Setup Parameter - 1st Pump Off Level
40014 √ √ Setup Parameter - 2nd Pump On Level
40015 √ √ Setup Parameter - 2nd Pump Off Level
40016 √ √ Setup Parameter - 3rd Pump On Level
40017 √ √ Setup Parameter - 3rd Pump Off Level
40018 √ √ Setup Parameter - 4th Pump On Level
40019 √ √ Setup Parameter - 4th Pump Off Level
40020 √ √ Setup Parameter - High Level Alarm
40021 √ √ Setup Parameter - Low Level Alarm
40022 √ √
Remote Control - Forced Lead Pump Position (Same as Parameter P.39) 0 = Alternate
1 = Pump 1 Lead 2 = Pump 2 Lead 3 = Pump 3 Lead 4 = Pump 4 Lead
40023 √ Current Lead Pump Position
40025 √ √ Remote Level Input (Must set Parameter F.19 = 4.)
40035 √
40036 √
40037 √
40024 √ Calculated VFD Speed Reference (Percent of Full Speed, 0-100%)
160 159 158 157 156 155 154 153 152 151 150 149 148 147 146 145
Pump 4 Remote Control Disable Pump Operation Pump 3 Remote Control Disable Pump Operation Pump 2 Remote Control Disable Pump Operation Pump 1 Remote Control Disable Pump Operation Pump 4 Called to Run Pump 3 Called to Run Pump 2 Called to Run
Pump 1 Called to Run
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Coil
Bit
29
560 559 558 557 556 555 554 553 552 551 550 549 548 547 546 545
Discrete Input 8 Discrete Input 7 Discrete Input 6 Discrete Input 5 Discrete Input 4 Discrete Input 3 Discrete Input 2 Discrete Input 1
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit
Coil
576 575 574 573 572 571 570 569 568 567 566 565 564 563 562 561
Discrete Input 16 Discrete Input 15 Discrete Input 14 Discrete Input 13 Discrete Input 12 Discrete Input 11 Discrete Input 10
Discrete Input 9
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Coil
592 591 590 589 588 587 586 585 584 583 582 581 580 579 578 577
Level Probe Electrode 10 Level Probe Electrode 9 Level Probe Electrode 8 Level Probe Electrode 7 Level Probe Electrode 6 Level Probe Electrode 5 Level Probe Electrode 4 Level Probe Electrode 3 Level Probe Electrode 2 Level Probe Electrode 1 Discrete Input 18 Discrete Input 17
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Coil
Bit
Bit
