3
Parameter
Default
Value
Current
Value Setting Definitions
-
2.0 feet
Low Level Alarm SCADA Register 40021 Range: 0.1 - 99.9 feet
Note: To Disable Alarm see Parameter P.50.
-
3.0 feet 1st Pump Off Level SCADA Register 40013 Range: 0.2 - 99.9 feet
-
6.0 feet 1st Pump On Level SCADA Register 40012 Range: 0.2 - 99.9 feet
-
4.0 feet 2nd Pump Off Level SCADA Register 40015 Range: 0.2 - 99.9 feet
-
7.0 feet 2nd Pump On Level SCADA Register 40014 Range: 0.2 - 99.9 feet
-
4.5 feet 3rd Pump Off Level SCADA Register 40017 Range: 0.2 - 99.9 feet
-
8.0 feet 3rd Pump On Level SCADA Register 40016 Range: 0.2 - 99.9 feet
-
5.0 feet 4th Pump Off Level SCADA Register 40019 Range: 0.2 - 99.9 feet
-
9.0 feet 4th Pump On Level SCADA Register 40018 Range: 0.2 - 99.9 feet
-
10.0 feet High Level Alarm SCADA Register 40020 Range: 0.5 - 99.9 feet
-
5 sec. Lag Pump(s) Delay Range: 1 - 100 seconds
SEC
0
Security Code - Enter Your Security Code Here to Allow Parameters to be
Changed. Change to other Number to Re-lock All Parameters.
Note: The Security Code may be Customized using Parameter P.26. See Page 2.
P.13
4
Number of Pumps Present See Page 9.
1 = 1 Pump 2 = 2 Pumps 3 = 3 Pumps 4 = 4 Pumps
P.14
4
Number of Pumps Allowed to Run at the Same Time See Page 9.
1 = 1 Pump 2 = 2 Pumps 3 = 3 Pumps 4 = 4 Pumps
P.15
4
Number of Pumps Allowed to Run On Generator See Page 9.
1 = 1 Pump 2 = 2 Pumps 3 = 3 Pumps 4 = 4 Pumps
Note: Must Connect Transfer Switch Contacts to Discrete Input Programmed for Function 7.
P.16
1
Alternator Sequence Mode
1 = Standard Alternation See Page 11.
2 = Pump 1 Always Lead - Stays On With Other Pumps See Page 11.
3 = Pump 1 Always Lead - Turns Off With Other Pumps See Page 12.
4 = Split Alternation - Pumps 1&2, and Pumps 3&4 See Page 12.
5 = Fixed Sequence - Pump 1 Always Lead See Page 13.
6 = Stepped On/Off - Only One Pump Runs at a Time See Page 13.
P.17
2
Pump Stop Mode See Page 10.
1 = First On Last Off 2 = First On First Off
P.18
1
Automatic Alternation See Page 10.
1 = Enabled 2 = Disabled
P.19
1
Pump Up or Down Mode
1 = Pump Down - Empty a Tank 2 = Pump Up - Fill a Tank
Note: When Parameter P.19 is Changed New Default Level Parameter Values will be loaded.
P.20
-
P.23 - VFD Speed Control Setup See Page 21.
MENU - SYSTEM SETUP
All Level Settings Have the Decimal Point Artificially Inserted Based on Parameter P.36.
