4
Parameter
Default
Value
Current
Value Setting Definitions
P.24
11.5 feet
Level Input Calibration - Span Range: 0.9 - 99.9 feet See Page 20.
Notes:
1. 20mA is Typically Applied to the Analog Input while Setting the Span.
2. Parameter P.24 Shows the Wet Well Level, while allowing the Up & Down Push-buttons to
Change the Internal Number used to Calculate the Displayed Level.
3. When Controller is set to Operate using a Level Probe, Parameter P.24 shows “77.7”.
P.25
0.0 feet
Level Input Calibration - Zero
See Page 20.
Notes:
1. 4.0mA is Typically Applied to the Analog Input while Setting the Zero.
2. Parameter P.25 Shows the Wet Well Level, while allowing the Up & Down Push-buttons to
Change the Internal Number used to Zero the Displayed Level.
3. When Controller is set to Operate using a Level Probe, Parameter P.25 shows “77.7”.
P.26
0
Security Code Setup Parameter - Establishes What Value Will Be Accepted
as the Security Code at Parameter SEC. Range: 0 - 255
Notes:
1. To Change Parameter P.26, the Current Security Code Must First be Entered into SEC.
2. When You Change Parameter P.26 and Exit the Value Change Mode Parameter, P.26
Will No Longer Be Viewable, Until You Enter the New Security Code into Parameter SEC.
3. If You Forget Your Security Code, Consult the Factory for the Master Security Code.
P.28
1 Slave Address
See Page 25.
P.29 - P.32 - RS232 Serial Port Setup See Page 26.
P.33
1 Register Access Mode
See Page 25.
P.35
1 sec.
Stop Pump Delay Range: 1 - 100 seconds
Note: This is the Time Period that the Wet Well Level Must Remain At or Below (At or Above for
Pump Up P.19 = 2) the Respective OFF Level Setting in order to Turn Off a Pump.
P.36
1
Display Decimal Point Position
0 = No Decimal Point 1 = XX.X 2 = X.XX
P.37
1 min.
Pump Re-enable Delay after Float Backup Low Level (High Level)
Notes: Range: 1 - 255 minutes
1. Pump Down (Parameter P.19 = 1) - Delay Starts when the Low Level Float Input Opens.
2. Pump Up (Parameter P.19 = 2) - Delay Starts when the High Level Float Input Opens.
P.38
1 min.
Delay Canceling Remote Control Commands
Notes: Range: 0 - 254 minutes
1. Delay Starts when Serial Communication is Lost.
2. To Allow all Remote Commands to Remain in Effect (Until Power Loss) Set P.38 = 255.
P.39
0
Forced Lead Pump Position SCADA Register 40022
See Page 10.
0 = Normal Alternation 1(2,3,4) = Pump 1(2,3,4) as Lead
P.40 - P.43 - Flush Cycle Setup See Page 22.
P.44 - P.47 - Flow Calculator Setup See Pages 23 - 24.
P.49
240
Analog Level Input - Signal Conditioning Control Range: 1 - 254
10 = Very Slow 100 = Slow 240 = Normal 250 = Fast
P.50
1
Low Level Alarm Mode 0 = Disabled 1 = Enabled
Note: Setting “0” Disables Low Level Alarms from the Analog Level Input or Level Probe Inputs.
P.51
0
Time Based Alternation Range: 1 - 255 1/6 hour
See Page 10.
0 = Disabled 1 = 1/6 hour 6 = 1 hour 48 = 8 hours 144 = 24 hours
FLC -
Fault Code SCADA Register 40047 See Fault Code Table on Pages 18 - 19.
Note: This Automatically Returns to Zero when the Fault Clears (Except for Faults 20-29).
LFC -
Last Fault Code SCADA Register 40048 See Fault Code Table on Pages 18 - 19.
Note: This is a Copy of the Last Non-Zero Fault Code that was shown on Parameter FLC.
oPr -
Operating Program Revision Number - Controller SCADA Register 40063
EPr -
Operating Program Revision Number - Ethernet Board
MENU - SYSTEM SETUP
All Level Settings Have the Decimal Point Artificially Inserted Based on Parameter P.36.
