MPE SC2000 - Page 9

8
Parameter Data Description
n.01
Discrete Input 1 Status
Discrete Input Status
0 = Input Open
1 = Input Closed
Notes:
1. Discrete Input Status is used when troubleshooting the
wiring and logic connected to the Discrete Inputs.
2. Discrete Input Status data may be read by SCADA at
Registers 40035 - 40037. See Page 29 .
n.02
Discrete Input 2 Status
n.03
Discrete Input 3 Status
n.04
Discrete Input 4 Status
n.05
Discrete Input 5 Status
n.06
Discrete Input 6 Status
n.07
Discrete Input 7 Status
n.08
Discrete Input 8 Status
n.09
Discrete Input 9 Status
n.10
Discrete Input 10 Status
n.11
Discrete Input 11 Status
n.12
Discrete Input 12 Status
n.13
Discrete Input 13 Status
n.14
Discrete Input 14 Status
n.15
Discrete Input 15 Status
n.16
Discrete Input 16 Status
n.17
Discrete Input 17 Status
n.18
Discrete Input 18 Status
n.19
Auxiliary Analog Input 1 Status
Auxiliary Analog Input Status Range: 0 - 255
Where: 0 = 0.0 mA 51 = 4.0 mA 255 = 20 mA
Note: Auxiliary Analog Input data may be read by SCADA
in either an 8-Bit or 10-Bit format. See Page 30.
n.20
Auxiliary Analog Input 2 Status
n.21
Auxiliary Analog Input 3 Status
n.22
Auxiliary Analog Input 4 Status
d.01
Voltage of +5 Volt Power Supply SCADA Register 40049 Normal Range: 8.5V - 11.3V
Note: Voltage is measured ahead of Voltage Regulator.
d.02
Voltage of +24 Volt Power Supply SCADA Register 40050 Normal Range: 21.1V - 25.5V
d.03
Pump 1 VFD Speed Reference (Percent of Full Speed, 0 - 100%) SCADA Register 40038
d.04
Pump 2 VFD Speed Reference (Percent of Full Speed, 0 - 100%) SCADA Register 40039
d.05
Pump 3 VFD Speed Reference (Percent of Full Speed, 0 - 100%) SCADA Register 40040
d.06
Pump 4 VFD Speed Reference (Percent of Full Speed, 0 - 100%) SCADA Register 40041
d.07
Serial Communication Activity Indicator See Page 34.
d.08
Serial Communication – Shows the Address of the Last Slave Polled by the Master See Page 34.
d.09
Serial Communication – Shows the Last Modbus Function Code Received See Page 34.
d.10-d.86
Serial Communication – Shows the Entire Rest of the Last Modbus Message Received
MENU - DATA DISPLAY
