MPE SC2000 - Page 8

7
Parameter Data Description
L.01
Electrode 1 Status Value
Level Probe Electrode Status Values
Normal Range when Un-Covered: 240 - 255
Normal Range when Covered by Typical Sewage: 55 - 70
Notes:
1. The Controller compares each of the Electrode Status Values with what is set on
Parameter F.22. When the value drops below the setting on Parameter F.22, the
Controller logic considers the Electrode to be covered by liquid.
2. Parameters L.01 - L.10 are also used to diagnose Out of Sequence Faults (Fault
Codes 21 - 29).
3. For the status of the Level Probe inputs see Coils 583 - 592 in SCADA Register
40037.
L.02
Electrode 2 Status Value
L.03
Electrode 3 Status Value
L.04
Electrode 4 Status Value
L.05
Electrode 5 Status Value
L.06
Electrode 6 Status Value
L.07
Electrode 7 Status Value
L.08
Electrode 8 Status Value
L.09
Electrode 9 Status Value
L.10
Electrode 10 Status Value
L.11
Level Probe Test Signal Status Normal Range: 230 - 254
Note: This is a Measure of the ±8V, 60Hz Square Wave Sent Out to Each Electrode to read the level. If the value is below
210, a malfunction has occurred in the circuit that provides the Square Wave used to read the level. In this case the wet
well level display will show zero, the Fault indicator will be turned on, and Fault Code 20 will be generated.
FLH
Flow Calculator - Latest Inflow Rate FLH , FLL Gallons Per Minute
See pages 18 - 19. SCADA Register 40080
FLL
FdH
Flow Calculator - Average Daily Inflow Total FdH , FdL Units set by Parameter P.45.
See pages 18 - 19. SCADA Register 40081
FdL
F1H
Flow Calculator - Pump 1 Outflow Rate F1H , F1L Gallons Per Minute
See pages 18 - 19. SCADA Register 40082
F1L
F2H
Flow Calculator - Pump 2 Outflow Rate F2H , F2L Gallons Per Minute
See pages 18 - 19. SCADA Register 40083
F2L
F3H
Flow Calculator - Pump 3 Outflow Rate F3H , F3L Gallons Per Minute
See pages 18 - 19. SCADA Register 40084
F3L
F4H
Flow Calculator - Pump 4 Outflow Rate F4H , F4L Gallons Per Minute
See pages 18 - 19. SCADA Register 40085
F4L
MENU - DATA DISPLAY
