Use Instructions
EchoTable User Manual Page 21 of 45 DCR-00576
(MAN-0011-D)
Using the Carotid Head Rest
The product may be equipped with an optional head support to provide better access
during carotid artery scanning. Prior to using the head support the mounting brackets
must be installed at the head end of the product.
The head rest mount is located
underneath the head end of the Fowler
section.
Install the head rest and adjust the
location. Tighten the knob on the head
rest mount to secure.
Adjust the height and orientation of the
head rest using the two control knobs.
Tighten to secure.
WARNING
• Verify the head rest is secure prior to using the product.
