MPower CRB7 - Items Enclosed

1
5
4
1D
6E
3
4B
5B
5D 5E
6
6B
6D
6F
1B
1C
2 2B
16 4 3 27 1 2 3 4 5 6 7
123 1 2 3
cm
Inches
5
11
1 Bridge
1B Bridge Spacer
1C Bridge Slot
1D Bridge pinch bolt hole
2 Baseplate
2B Baseplate Letterbox
3 Bridge Pinchbolt
4 Micro Adjuster
4B Micro Adjuster Lock Nut
5 Adjuster Guide Rod 5/16” (8mm)
5B Adjuster Guide Rod M5 Locknut
5D Adjuster Rod
5E Adjuster Rod Crank Plate
6 Fixed Guide Rod 5/16” (8mm)
6B Fixed Guide Rod M5 Locknut
3
ITEMS ENCLOSED
6D Fixed Rod
6E Fixed Rod M8 Locknut x 2
6F Fixed Rod Crank Plate
7 Offset Handle
8 Anti-tilt Leg
9 Pivot Pin
10 Mortise Pillars
11 Self adhesive Rule
12 No.6 x 1/2” Woodscrews x 6
13 M4 x 25/64’ (10mm) Screws x 3
14 9/32” (7mm) Guide Rods
15 Compass Pivot Hub
16 25/64” (10mm) Compass Rods x 2
17 No.6 x 1/2” Woodscrews x 3
18 Lock Bars X 2
(not to scale)
7
8
10
13
13
9
12
Accessories
15
18
16
14
X 6
17
X3
