MPower CRB7 - Setting Up; Fitting the CRB7 to Router

4
FITTING THE CRB7 TO YOUR ROUTER
1. Guide Rod selection
5
6
6E
4B
3. Initial alignment
Aligned
5
Router base
wing bolt
A
SETTING UP
Letterbox
The CRB7 is fitted with 5/16” (8mm) diameter
guide rods (5 & 6).
If the router base rod drillings are smaller, fit
the 9/32” (7mm) guide rods.
2. Loosen the Lock Nuts
Using 1 x 1/2” (13mm) spanner, slightly loosen
fixed rod nut (6E) and micro adjuster nut (4B).
Position the router in front of the CRB7.
Align the router base rod drilling (A) with
Adjuster Rod (5).
IMPORTANT
IT IS NOT ESSENTIAL TO CENTER THE
ROUTER CUTTER PRECISELY WITHIN
THE CRB7’S LETTERBOX FOR ANY
OPERATION.
