MPPT SPT-10A User Manual

23
Environmental Parameters
Environmental
Parameters
LCD temperature range Working
environment
-20°C +70°C
temperature range*
-25°C +45°C
Storage temperature range
-35°C +80°C
Humidity range
95%(N.C.)
Enclosure
IP30
*Please operate controller at permitted ambient temperature. If over permissible range,
pIease derate capacity in service.
Mechanical Parameters
Mechanical
SPT-10A
SPT-15A
SPT-20A
SPT-25A
Dimension
171.7mm x 154mm x 49.3mm
219.3mm x 154mm x 54.9mm
Mounting dimension
142.2mm x 67.4mm
142.2mm x 125mm
Mounting hole size
Ф6.2
Power Terminals
12AWG (4mm
2
)
6AWG (16mm
2
)
Weight
670g
1000g
Mechanical Parameters
Mechanical
SPT-30A
SPT-35A
SPT-40A
SPT-45A
Dimension
226.8mm x 179.2mm x 59.3mm
250.8mm x 179.2mmx 62.4mm
Mounting dimension
167.5mm x 123.4mm
167.5mm x 147.4mm
Mounting hole size
Ф6
Power Terminals
6AWG (16mm
2
)
6AWG (16mm
2
)
Weight
1280g
1900g
