MRC DO-5510 User Manual

Each digit indicate the following status :
D15 Start Word =02
D14 Reading Polarity for the Display.
0 =Both upper & lower display value are "+".
1 =Upper "-", Lower "+".
2 =Upper "+", Lower "-".
3 =Both upper & lower display value are "-".
D13 Anunuciator for Lower Display
0
=
No Symbol 1
=
℃ 2 =℉
D12 & D11 Anunuciator for Upper Display
01
=
℃ 07 =mg/L
02
=
℉ 06 = % O2
D10 Decimal Point (DP) for lower display
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D9 Decimal Point ( DP) for Upper display.
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D8 to D5 Lower Display reading, D5=LSD, D8=MSD
D4 to D1 Upper Display reading, D1=LSD, D4=MSD
D0 End Word = 0D
RS232 setting
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
13
