Each digit indicates the following status :
D0 End Word
D1 & D8 Display reading, D1 = LSD, D8 = MSD
For example :
If the display reading is 1234, then D8 to D1 is :
00001234
D9 Decimal Point(DP), position from right to the left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10 Polarity
0 = Positive 1 = Negative
D11 & D12 Annunciator for Display
Lux = 15 Ft-cd = 16
D13 When send the upper display data = 1
When send the lower display data = 2
D14 4
D15 Start Word
RS232 FORMAT : 9600, N, 8, 1
7. BATTERY REPLACEMENT
1)When the left corner of LCD display show " ",
is necessary to replace the battery. However, in-spec.
measurement may still be made for several hours after
low battery indicator appears.
2)Slide the " Battery Cover " ( 3-10, Fig. 1 ) away from the
instrument and remove the battery.
3)Replace with 9V battery ( Alkaline or Heavy duty type )
and reinstate the cover.
4)Make sure the battery cover is secured after changing the
battery.
11
MRC.7.2022
