3. FRONT PANEL DESCRIPTION
3-1 Display 3-8 Light Sensor Input Socket
3-2 Power Button 3-9 Stand
3-3 Hold Button 3-10 Battery Compartment/Cover
3-4 REC ( Max/Min ) Button 3-11 RS-232 Output
3-5 Lux/Fc ( Ft-cd ) Button 3-12 Light Sensor
3-6 Range Button 3-13 Sensor Cover
3-7 Zero Button 3-14 Light Sensor Plug
3-15 LCD display contrast adjust VR.
