Operating manual
Page 18
Figure 10 – Adding parameters to display an averaged value
The following controls are presented in drop-down list Data for filter, see Table 8.
Table 8 – Controls of filter list
Name
Function
ОК
To confirm the select
Cancel
To cancel the selected settings
To add a filter
To delete all filters
Time intervals to average values of the given parameter shall be entered into white
fields after select of filter parameters, see Figure 11.
Figure 11 – Adding parameters to get an averaged value
The following controls are located in Filters the input data, see Table 9.
