Universal digital repeater
DR-209M
Page 31
Cancel
To cancel the selected settings
« »
Back to Screen setup
« »
To confirm the select of data source settings
2.3.13 Tab page СОМ
The structure of Ports tab page is represented in Figure 23. Ports tab page, see
Figure 24 is intended to configure reception / transmission of data for each port, to set
parameters of NMEA sentences received by each port, as well as to provide individual
settings for each port (baud rate, stop bits, parity, type).
Figure 23 – The structure of СОМ tab page
2.3.13.1 Configuration of data reception / transmission
To provide settings (edit) of data reception / transmission, select a port, e.g.
СОМ1. In the field of this port opposite to the selected NMEA data in Transmitting press
« », see Figure 23.
