Model S4100C
3
2.3 Mechanical
Height excl. Sensor:
150mm (6”)
Height incl. Sensor:
200mm (8”)
Width:
150mm (6”)
Depth:
95mm (3.75”)
Weight including Sensor:
2.5kg (5.5lbs)
Mounting Holes:
4 x 7 mm (0.28”) dia holes
Termination:
Ex e rated Terminal Block
2.4 Environmental
Operating temperature range (continuous) min/max
- 40C to + 70C
Storage temperature range min/max
- 50C to + 85C
Relative humidity min/max:
5% to 100%, non-condensing
Operating Altitude max:
8000 ft
Non-operating Altitude max:
16000 ft
EMI/RFI Susceptibility;
IP Rating:
IP66/67
2.5 Electrical
Supply voltage min/max:
10VDC/35VDC operating
Supply voltage abs min/max:
8VDC/40 VDC
Supply voltage ripple & noise max.
1Vpp
Supply current consumption, including sensor typ/max:
250mA/310mA @ 24 VDC
500mA/620mA @ 12 VDC
Supply fuse rating: 18VDC – 35VDC operation
10VDC – 35VDC operation
500mA Chart “T” PC  1500A
1A Chart “T” PC  1500A
Supply voltage low detection threshold min/max: 9.20VDC/10.32 VDC
Sensor Bias Current (Rsensor + Rcable = 6ohms –30ohms):
300mA  10mA
Sensor Bias Current (Rsensor + Rcable = zero ohms) max: 410mA
Sensor Cable Resistance per conductor max:
5 ohms
Analogue output Current Range:
0 – 22.0mA
Analogue Signal Startup
4 m A  0.2mA
Analogue Signal 0-100% LEL
4 - 2 0 m A
Analogue Output Current abs max:
22.1mA
Analogue Output Current Ripple and Noise max.
20uApp
Meets
EN 50270
EN55011: ENV50204
EN 61000-4-2: EN 61000-4-4: EN 61000-4-6
EN 61000-4-3: EN 61000-4-5: EN 61000-4-8
