You can install single sided or double sided 168-pin DIMMs into DIMM
slots according to your needs.
Module Installation Procedures
Single Sided DIMM
Double Sided DIMM
1. The DIMM slot has 2 Notch Keys VOLT and DRAM, so the
DIMM memory module can only fit in one direction.
2. Insert the DIMM memory module vertically into the DIMM slot.
Then push it in.
3. The plastic clips at sides of the DIMM slot will automatically
close.
VOLTDRAM
