Introduction
1-5
Quick Components Guide
Component Function Reference
DIMM1~4 Installing SDRAM modules See p. 2-5~2-6
Socket 370 Installing CPU(s) See p. 2-2~2-3
CPUFAN1/2 Connecting to CPUFAN See p. 2-21
SYSFAN Connecting to SYSTEM FAN See p. 2-21
ATX Power Supply Installing power supply See p. 2-7
IDE1& IDE2 Connecting to IDE hard disk drive See p.2-13
IDE3& IDE4 Connecting to IDE RAID HDD See p.2-14
FDD1 Connecting to floppy disk drive See p.2-12
USB2 Connecting to USB interface See p. 2-22~2-24
PCI Slot 1~5 Installing expansion cards See p. 2-29
AGP Slot Installing AGP cards See p. 2-29
CNR Slot Installing expansion cards See p. 2-29
JMDM1 Connecting to modem module See p. 2-19
JWOL1 Connecting to LAN card See p. 2-19
JBAT1 Clearing CMOS data See p. 2-28
JFP1 Connecting to case See p. 2-15
JGS1 Connecting to power saving switch See p. 2-18
JGL1 Connecting to power saving LED See p. 2-17
J3 Connecting to IR module See p. 2-20
JRMS1 Connecting to power switch See p. 2-18
J6 Connecting to HDD LED See p. 2-20
J11 & J12 Connecting to IEEE 1394 interface See p. 2-26~2-27
JP1 Connecting to D-Bracket See p. 2-25
