Overview of Components
M.2 slots with examples of various combination possibilities
1xM.2 PCIe SSD + 6xSATA HDDs
2xM.2 PCIe SSDs + 6xSATA HDDs
M.2 PCIe
1xM.2 SATA SSD + 6xSATA HDDs
M.2 SATA
1xM.2 SATA SSD + 1xM.2 PCIe SSD
+ 6xSATA HDDs
1xM.2 SATA SSD + 2xM.2 PCIe SSD
+ 6xSATA HDDs
M.2 SATA
M.2 PCIe
SATA2 SATA6
SATA5SATA1
SATA4 SATA3
3xM.2 PCIe SSDs + 4xSATA HDDs
SATA2 SATA6
SATA5SATA1
SATA4 SATA3
M.2 PCIe
M.2 PCIe
SATA2 SATA6
SATA5SATA1
SATA4 SATA3
SATA2 SATA6
SATA5SATA1
SATA4 SATA3
For Chipset mode these two
PCIe x1 slots are un-available.
(Default)
For CPU mode these two PCIe x1
slots are available.
M.2 PCIe
M.2 PCIe
M.2 PCIe
SATA2 SATA6
SATA5SATA1
SATA4 SATA3
For Chipset mode these two
PCIe x1 slots are un-available.
(Default)
For CPU mode these two PCIe x1
slots are available.
M.2 SATA
M.2 PCIe
M.2 PCIe
SATA2 SATA6
SATA5SATA1
SATA4 SATA3
