17
󶵪󱠁󴚯󸷇 󶵪󱠁󴚯󸷇
󴳈󳠵
󳞄󲁗󱟨󲖬󱛉󸝬󳿒󹶉󳩳󸹃󵢋
󹶉󳩳󳲝󲁅
󴟛󳓑󹶉󳩳󳲝󲁅󱣎󵭡󸹃󵢋󳲡󱵺󱥰󲁣󳳣󱣼󳛲󲹥󵷜󸳹󱴤󲅈󸝬󷓀󹶉󳩳󸹃󵢋󳕖󳞄󲽀󱚋
󱛅󹛳󷆧󹬯󹶉󳩳󳳧󱰪󱵰󴟛󳓑󱚘󹶉󳩳󳲝󲁅󴃂󽚟󹶉󳩳󸹃󵢋󲽀󲩈󶵮󱥦󳮓󲖬
󽚟󸶓󲁗󷅮󱠸󱞅󵭔󳖲󲣴󲑢󲢒
1
󴟛󳓑󹛳󷆧󲹥󱛴
1 Ground 2 +12V
3 Sense 4 Speed Control Signal
󳲝󲁅 󺟢󸜍󹶉󳩳󴟛󳓑 󴉶󲣴󵭳󴵌 󴉶󲣴󱸪󵢋
CPU_FAN1 󴟛󳓑 2A 24W
SYS_FAN1 󴟛󳓑 1A 12W
1
󴟛󳓑󹛳󷆧󲹥󱛴
1 Ground 2 Voltage Control
3 Sense 4 NC
1
2
12
11
1 SPI Power 2 SPI Chip Select
3
Master In Slave Out (SPI
Data)
4
Master Out Slave In (SPI
Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request
󴟛󶵪󳲝󲁅
󴨠󳲝󲁅󴄡󵭡󴌟󸶚󳲝󲹁󱰰󳎦󲁙󴟛󶵪󸝠󲀐󶽰󲹁󱰰󳎦󲁙󳩿󱱧󱟨󷝊󳗈󴉣󲣘󶵬󷓀󲅈
󵭡󴲥
Downloaded from ManualsNet.com search engine

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI B560M PRO WIFI and is the answer not in the manual?

MSI B560M PRO WIFI Specifications

General IconGeneral
ChipsetIntel B560
Form FactorMicro ATX
SocketLGA 1200
Memory Slots4 x DIMM
Max Memory128 GB
LANRealtek RTL8125B 2.5Gbps
Audio CodecRealtek ALC897
PCIe Slots1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1
Storage Interface6 x SATA 6Gb/s
WirelessWi-Fi 6
Bluetooth5.1
Video Outputs1 x HDMI, 1 x DisplayPort
USB Ports6 x USB 3.2 Gen 1, 6 x USB 2.0
