3
Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel®
Core™ Processors, Pentium® Gold and Celeron® Processors
Processor socket LGA1200
* Please go to intel.com for compatibility information.
Intel® B560 chipset
2x DDR4 memory slots, support up to 64GB*
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU
(by JEDEC & POR)
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel®
CPU (by JEDEC & POR)
Max overclocking frequency:
1DPC 1R Max speed up to 5200 MHz
1DPC 2R Max speed up to 4700+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on
compatible memory.
1x PCIe x16 slot
PCI_E1 (From CPU)
Supports PCIe 4.0 for 11th Gen Intel® CPU
Supports PCIe 3.0 for 10th Gen Intel® CPU
2x PCIe 3.0 x1 slots
PCI_E2 & PCI_E3 (From B560 chipset)
1x HDMI 2.0b with HDR port, supports a maximum
resolution of 4K 60Hz*
/
**
1x VGA port, supports a maximum resolution of 2048x1536
60Hz, 1920x1200 60Hz*
1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz*
/
**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU
installed.
Continued on next page
