MSI B560M PRO WIFI User Manual


 
Continued from previous page


 1x 24-pin ATX main power connector
 1x 8-pin ATX 12V power connector
 6x SATA 6Gb/s connectors
 1x M.2 slot (M-Key)
 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
 1x 4-pin CPU fan connector
 1x 4-pin system fan connector
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x Clear CMOS jumper
 1x TPM module connector
 1x Serial port connector
 1x Tuning Controller connector


 1x HDMI port
 1x VGA port
 1x DisplayPort
 1x PS/2 keyboard/ mouse combo port
 2x USB 2.0 Type-A ports
 4x USB 3.2 Gen 1 5Gbps Type-A ports
 1x 2.5Gbps LAN (RJ45) port
 2x Wi-Fi Antenna connectors
 3x audio jacks

 4x EZ Debug LED
 1x 4-pin RGB LED connector
 1x 3-pin RAINBOW LED connector
 NUVOTON NCT6687-R Controller Chip
Continued on next page
Downloaded from ManualsNet.com search engine

MSI B560M PRO WIFI Specifications

General

Chipset	Intel B560
Form Factor	Micro ATX
Socket	LGA 1200
Memory Slots	4 x DIMM
Max Memory	128 GB
LAN	Realtek RTL8125B 2.5Gbps
Audio Codec	Realtek ALC897
PCIe Slots	1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1
Storage Interface	6 x SATA 6Gb/s
Wireless	Wi-Fi 6
Bluetooth	5.1
Video Outputs	1 x HDMI, 1 x DisplayPort
USB Ports	6 x USB 3.2 Gen 1, 6 x USB 2.0
