Package Contents
Unpack the package and inspect all the items carefully. If any item con-
tained is damaged or missing, please contact your local dealer as soon as
possible. Also, keep the box and packing materials in case you need to
ship the unit in the future.
Your VGA card package should contain the following items:
VGA Card
Software
Pack CDs
User’s Manual
Reference
2. INTRODUCTION ............................................................................ 2-1
3. HARDWARE INSTALLATION ........................................................ 3-1
3.1 Card Installation ..................................................................... 3-2
3.2 D-Sub Port (DB 15-Pin) ......................................................... 3-5
3.3 Digital Panel Connector (DVI-I) ............................................ 3-6
3.9 TV_Out / Video_In Connector (S&C) .................................. 3-10
4. SOFTWARE INSTALLATION ......................................................... 4-1
5. MSI LIVE UPDATE 3 ....................................................................... 5-1
5.1 Installing MSI Live Update 3 with MSI Live Monitor .............. 5-2
5.2 Using the MSI Live Update 3 .................................................. 5-3
5.3 Live VGA Drive Update .......................................................... 5-4
5.4 Live VGA BIOS Update .......................................................... 5-8
5.5 Live Utility ............................................................................. 5-14
5.6 How to Use the MSI Live Monitor ......................................... 5-15
5.7 Contact Us ............................................................................ 5-22
6. TROUBLESHOOTING ................................................................... 6-1
DVI-I / VGA Adapter
TV_Out / Video_In 1-
to-4 Connecting Cable
+ Remote Receiver
Remote Controller
TV-Out S-S
Connecting Cable
To Next Page
