CPU & Cooler Installaton
When you are nstallng the CPU, make sure the CPU has a cooler attached on the top
to prevent overheatng. Meanwhle, do not forget to apply some thermal paste on CPU
before nstallng the heat snk/cooler fan for better heat dsperson.
Follow the steps below to nstall the CPU & cooler correctly. Wrong nstallaton wll
cause the damage of your CPU & manboard.
The CPU socket has a plastc cap on
t to protect the contact from damage.
Before you nstall the CPU, always
cover t to protect the socket pn.
1.
Remove the cap
from lever hnge
sde (as the arrow shows).
2.
The pns of socket reveal.3. Open the load lever.4.
Important
Con󰘰rm f your CPU cooler s 󰘰rmly nstalled before turnng on your system.dfgda-
fgsedgadfgagasgasgsag
Do not touch the CPU socket pns to avod damagng.
The avalablty of the CPU land sde cover depends on your CPU packng.
•
•
•
