MSI G45TM-E53 Series - Hardware Setup

A-19
MS-7609
hardware Setup
Connectng the Speakers
When you have set the Mult-Channel Audo Functon mode properly n the software
utlty, connect your speakers to the correct phone jacks n accordance wth the settng
n software utlty.
2-Channel Mode for Stereo-Speaker Output
Lne In
Lne Out (Front channels)
MIC
No functon
No funct
on
No functon
■
1]
2]
3]
4]
5]
6]
