Led StatuS indicatorS
APS LEDs
These APS (Actve Phase Swtchng) LEDs ndcate the current CPU power phase
mode. Follow the nstructons
below to read.
: ON, : OFF
3 of the LEDs wll lght blue when CPU s n 3 phase power mode.
2 of the LEDs wll lght blue when CPU s n 2 phase power mode.
1 of the LEDs wll lght blue when CPU s n 1 phase power mode.
APS LEDs
