14
Rear I/O Panel
Realtek Audio Console
better sound experience.
Device Selection
options. The check sign indicates the devices as default.
Application Enhancement
guidance of anticipated sound effect for both output and input device.
Main Volume
that you plugged in front or rear panel by adjust the bar.
Jack Status
computer.
Connector Settings
Auto popup dialog
When you plug into a device at an audio jack, a dialogue window will pop up asking you
which device is current connected.
Each jack corresponds to its default setting as shown on the next page.
Important
The pictures above for reference only and may vary from the product you purchased.
Jack Status
Device
Selection
Main Volume
Application Enhancement
To Next Page
