MSI GAMING PLUS MPG Z590 User Manual

28
Overview of Components
CPU_FAN1, PUMP_FAN1, SYS_FAN1~6: Fan Connectors

PWM Mode fan connectors provide constant 12V output and adjust fan speed with



manually.
Switching fan mode and adjusting fan speed
BIOS >
HARDWARE MONITOR.
Select PWM mode or DC mode

Important

There are gradient points of the fan speed that allow you to adjust

Pin definition of fan connectors
Connector
Default
fan mode
Max.
current
Max.
power
 Auto mode 2A 24W
PUMP_FAN1 PWM mode 3A 36W
  1A 12W
1
PWM Mode pin definition
1 Ground 2 
3 Sense 4 
1
DC Mode pin definition
1 Ground 2 
3 Sense 4 
SYS_FAN1
SYS_FAN5
SYS_FAN3
SYS_FAN2
PUMP_FAN1

SYS_FAN4
SYS_FAN6

MSI GAMING PLUS MPG Z590 Specifications

General

Chipset	Intel Z590
Form Factor	ATX
Socket	LGA 1200
Memory Slots	4
Max Memory	128GB
PCIe 4.0 x16 Slots	1
PCIe 3.0 x16 Slots	1
PCIe 3.0 x1 Slots	2
M.2 Slots	3
SATA 6Gb/s Ports	6
USB 3.2 Gen 2x2 Ports	1
USB 2.0 Ports	6
LAN	Realtek RTL8125B 2.5Gbps
RAID Support	0, 1, 5, 10
Memory Speed	5333 MHz (OC)
USB 3.2 Gen 2 Ports	2
Audio	Realtek ALC897
